3 Pc Threaded Ball Valve

Collect
Product No. 0123
Product Description

3 Pc Wafer Ball Valve

3 Pc ball valve and the gate valve are the same type of valve, the difference is that its closing part is a sphere, and the sphere rotates around the center line of the valve body to open and close a valve.

3 Pc ball valve is mainly used to cut off, distribute and change the flow direction of the medium in the pipeline.


Product Name:
Stainless Steel Sanitary 3PC Non Retention Threaded Manual Ball Valve
Valve Body Material:
1.4404/1.4301, SS304/SS316L(Forged)
Gasket Material:
EPDM (standard)
Surface Finishing
RA<0.8 um
Seal:
PTFE
Max Working Pressure:
10 Bar
Max. Working Tem.:
120 degree C
Availably Size:
DN25-DN100,1/2"-4"
Features
Compact and robust design










PED 2014/68/EU
The valve body can be changeable with any kind of connection
Availably standard:
DIN/SMS/RJT/ISO/IDF
Operated:
Electric
Options
Gasket: EPDM, silicone or Viton
Connection:weld,clamp,thread,weld thread,flange
Control:
Sensor, Pneuamtic actuator(single acting, double acting), electric actuato, C-TOP, C-top controller(AS-I)
Certificate:
PED 2014/68/EU
