Wafer Type Stainless Steel Flanged Ball Valve

The wafer type ball valve is simple in structure, small in size and light in weight, and only consists of a few parts. And it only needs to rotate 90° to open and close quickly, the operation is simple, and the valve has good fluid control characteristics.

Product Usage:

Widely used in: SO2, steam, air, gas, ammonia, CO2 gas, oil, water, brine, lye, seawater, nitric acid, hydrochloric acid, sulfuric acid, phosphoric acid, etc. in chemical, petrochemical, smelting, pharmaceutical, food and other industries It is used as a regulating and shut-off device on the pipeline of the medium.

Structural features:

①The unique eccentric design enables frictionless transmission between the sealing surfaces, extending the service life of the valve.

②Elastic seal is produced by torque.

③The ingenious wedge-shaped design enables the valve to have the automatic sealing function of closing and tightening, and the sealing surfaces have compensation and zero leakage.

④Small size, light weight, light operation and easy installation.

⑤ According to user requirements, pneumatic and electric devices can be configured to meet the needs of remote control and program control.

⑥ The material of the replacement parts can be applied to various media, and the lining can be anti-corrosion (lining F46, GXPP, PO, etc.).

⑦ Continuous structure diversification: wafer, flange, butt welding.
