3 Pc Wafer Ball Valve

Collect

Product No. 0123

Product Description

3 Pc Wafer Ball Valve

3 Pc ball valve and the gate valve are the same type of valve, the difference is that its closing part is a sphere, and the sphere rotates around the center line of the valve body to open and close a valve.

3 Pc ball valve is mainly used to cut off, distribute and change the flow direction of the medium in the pipeline.

Product Name:	Stainless Steel Sanitary 3PC Non Retention Clamp Manual Ball Valve
Valve Body Material:	1.4404/1.4301, SS304/SS316L(Forged)
Gasket Material:	EPDM (standard)
Surface Finishing	RA<0.8 um
Seal:	PTFE
Max Working Pressure:	10 Bar
Max. Working Tem.:	120 degree C
Availably Size:	DN25-DN100,1/2"-4"
Features	Compact and robust design

	PED 2014/68/EU
	The valve body can be changeable with any kind of connection
Availably standard:	DIN/SMS/RJT/ISO/IDF
Operated:	Electric
Options	Gasket: EPDM, silicone or Viton
	Connection:weld,clamp,thread,weld thread,flange
Control:	Sensor, Pneuamtic actuator(single acting, double acting), electric actuato, C-TOP, C-top controller(AS-I)
Certificate:	PED 2014/68/EU
