American Standard Bellows Globe Valve
The Globe Valve is a valve used to control flow. It has a good flow control effect and can accurately control the flow. API production standards. Can be used in various industries like power plant, oil and gas, shipyard, and so on.
Item | Globe Valve |
Mounting Standard | ISO5211 mounting for multi-turn electric actuator and pneumatic control actuator |
Flange Standard | ANSI, JIS, DIN, GB |
Material | Stainless Steel, Cast Iron, Cast Steel |
Pressure | 100 bar (CLASS150/300/600) |
Medium Temperature | -10 to 400℃ |
Mediums | Water, oil, air, gas, and other mediums |
Applications | Power plant, paper and pulp, food and beverage, shipyard, water treatment, and so on |
Design & Manufacture Standard of ANSI Globe Valve: |
Design and manufacturer | ASME B16.34, API602 |
Face to Face | ASME B16.10 |
Connection Dimension | ASME B16.5, ASME B16.25 |
Inspection and Test | ISO5208, API598 |
Design & Manufacture Standard of JIS Globe Valve: |
Design and manufacturer | KS B2361 |
Face to Face | KS B2361 |
Connection Dimension | KS B2361 |
Inspection and Test | KS B2361 |
Design & Manufacture Standard of DIN Globe Valve: |
Design and manufacturer | DIN 3356 |
Face to Face | DIN 3202 |
Connection Dimension | DIN 2543 |
Inspection and Test | DIN 3230 |
Design & Manufacture Standard of GB Globe Valve: |
Design and manufacturer | GB/T 12235 |
Face to Face | GB/T 12221 |
Connection Dimension | JB/T 79 |
Inspection and Test | JB/T 9092 |
